0750 DUAL AXIS INCLINOMETER MODULES

The 0750 Series single and dual axis stand alone inclinometers utilize the proven capacitive 3D-MEMS sensing element technology and robust mechanics. This combination makes the modules suitable for e.g. heavy duty construction machines and industrial applications. The modules have a digital RS-485 interface.

The modules are approximately 30x30x13mm in size, and can be mounted with two M3 screws. Modules are equipped with a pigtail cable with open ends. The products are available for measuring ranges of ±30° and ±90°.

Standard industrial RS-485 interface enables long transmission distances and possibility to connect multiple modules, with individual addresses, to the same bus. In addition to inclination, temperature information is also available from the module. The modules also feature a built-in self-test function that can be activated externally.

Specifications

Supply Voltage +7V to +35V
Current consumption 20mA
Output RS-485
Data transfer speed 10Hz
Measuring Range ±30°
Measuring Axis X-Y
Offset FS/2
Offset Temperature Error 0-70°C: ±0.2°
-25-85°C: ±0.6°
Resolution 0.03°/LSB
Sensitivity 30°/FS
Sensitivity Temperature Error 0-70°C: ±0.2°
-25-85°C: ±0.5°
Non-Linearity ±0.1°
Frequency Response 18Hz
Cross-Axis Sensitivity 4%



Instruction Sheet
